01 |
513 438 98
|
Hose assy. DN 40 x 3100 |
1 |
InternBDB: DOL 42 / FL 2 | InternKon: 574 550 40 / 02
|
|
|
|
02 |
513 437 98
|
Hose assy. DN 40 x 3550 |
1 |
InternBDB: DOL 42 / FL 2 | InternKon: 574 550 40 / 01
|
|
|
|
03 |
512 344 98
|
Hose assy. DN 40 x 5750 |
1 |
InternBDB: DOL 42 / DOL 42 | InternKon: 574 550 40 / 03
|
|
|
|
04 |
512 345 98
|
Hose assy. DN 40 x 5650 |
1 |
InternBDB: DOL 42 / DOL 42 | InternKon: 574 550 40 / 04
|
|
|
|
05 |
513 440 98
|
Hose assy. DN 40 x 4600 |
1 |
InternBDB: DOL 42 / FL 2 | InternKon: 574 550 40 / 06
|
|
|
|
06 |
513 439 98
|
Hose assy. DN 40 x 4750 |
1 |
InternBDB: DOL 42 / FL 2 | InternKon: 574 550 40 / 05
|
|
|
|
07 |
512 348 98
|
Hose assy. DN 40 x 4600 |
1 |
InternBDB: DOL 42 / DOL 42 | InternKon: 574 550 40 / 07
|
|
|
|
08 |
512 349 98
|
Hose assy. DN 40 x 4300 |
1 |
InternBDB: DOL 42 / DOL 42 | InternKon: 574 550 40 / 08
|
|
|
|
09 |
007 137 98
|
Union |
8 |
InternBDB: Voss 42-LM /011 754 99 | InternKon: 574 550 40 / 20
|
|
|
|
10 |
385 243 40
|
Seal ring |
4 |
InternBDB: 2 "
|
|
|
|
11 |
319 156 99
|
Bolt |
16 |
InternBDB: M12x30 /912
|
|
|
|
12 |
130 630 40
|
Half flange |
16 |
InternBDB: 50 / 210
|
|
|
|
13 |
374 415 99
|
Union |
1 |
InternBDB: L 42 M
|
|
|
|
14 |
647 851 40
|
Orifice |
4 |
InternBDB: DKG | InternKon: 574 550 40 / 50
|
|
|
|
17 |
534 002 99
|
Weld on plate |
5 |
InternBDB: S-AP-S-2 | InternKon: 574 550 40 / 49
|
|
|
|
18 |
502 682 98
|
Half clamp Ш 25 |
20 |
InternBDB: S-3-G-28 | InternKon: 574 550 40 / 36
|
|
|
|
19 |
504 585 98
|
Screw |
4 |
InternBDB: S-2 | InternKon: 574 550 40 / 41
|
|
|
|
20 |
504 586 98
|
Locking plate |
4 |
InternBDB: S - 2 | InternKon: 574 550 40 / 40
|
|
|
|
21 |
534 001 99
|
Cover plate |
5 |
InternBDB: S-DP-A-2 | InternKon: 574 550 40 / 46
|
|
|
|
22 |
308 579 99
|
Bolt |
10 |
InternBDB: M10x60 /931 | InternKon: 574 550 40 / 47
|
|
|
|
23 |
509 308 98
|
Locking plate |
5 |
InternBDB: SI 4 | InternKon: 574 550 40 / 48
|
|
|
|
25 |
534 009 99
|
Weld on plate |
7 |
InternBDB: S-AP-A-4 | InternKon: 574 550 40 / 44
|
|
|
|
26 |
506 371 98
|
Half clamp Ш 40 |
28 |
InternBDB: S-4-E-PA | InternKon: 574 550 40 / 29
|
|
|
|
27 |
504 786 98
|
Screw |
12 |
InternBDB: S-6 | InternKon: 574 550 40 / 34
|
|
|
|
28 |
504 787 98
|
Locking plate |
6 |
InternBDB: S - 4 | InternKon: 574 550 40 / 35
|
|
|
|
29 |
534 008 99
|
Cover plate |
7 |
InternBDB: S-DP-A-4 | InternKon: 574 550 40 / 31
|
|
|
|
30 |
308 459 99
|
Bolt |
14 |
InternBDB: M12x100 /931 | InternKon: 574 550 40 / 32
|
|
|
|
31 |
509 310 98
|
Locking plate |
14 |
InternBDB: SI 6 | InternKon: 574 550 40 / 33
|
|
|
|
32 |
534 005 99
|
Weld on plate |
2 |
InternBDB: S-AP-A-3 | InternKon: 574 550 40 / 37
|
|
|
|
33 |
502 656 98
|
Half clamp Ш 25 |
4 |
InternBDB: S-3-G-34 | InternKon: 574 550 40 / 42
|
|
|
|
34 |
502 960 99
|
Cover plate |
2 |
InternBDB: S-AP-S-3 | InternKon: 574 550 40 / 43
|
|
|
|
35 |
308 581 99
|
Bolt |
4 |
InternBDB: M10x70 /931 | InternKon: 574 550 40 / 38
|
|
|
|
36 |
509 309 98
|
Locking plate |
2 |
InternBDB: SI 5
|
|
|
|
40 |
906 480 40
|
Olive |
8 |
InternBDB: ES-4 L42 VOSS 0011452000 | InternKon: 574 550 40 / 57
|
|
