01 |
|
Non-return valve |
6 |
InternBDB: 902 510 40 | InternKon: 647 801 40 / 2
|
114-1821a |
|
|
02 |
513 825 98
|
Hose assy. DN 50 x 4700 |
1 |
InternBDB: FS 2 / FS 2 - 90 | InternKon: 674 955 40 / 1
|
|
|
|
03 |
512 544 98
|
Hose assy. DN 50 x 4500 |
1 |
InternBDB: FS 2 / FS 2 | InternKon: 674 955 40 / 2
|
|
|
|
04 |
512 315 98
|
Hose assy. DN 50 x 3550 |
1 |
InternBDB: FS 2 / FS 2 - 90 | InternKon: 674 955 40 / 3
|
|
|
|
05 |
513 207 98
|
Hose assy. DN 50 x 2750 |
1 |
InternBDB: FS 2 / FS 2 - 90 | InternKon: 674 955 40 / 4
|
|
|
|
06 |
371 519 40
|
Hose assy. DN 50 x 1500 |
1 |
InternBDB: FS 2 / FS 2 - 90 | InternKon: 674 955 40 / 6
|
|
|
|
07 |
324 651 40
|
Hose assy. DN 50 x 2500 |
1 |
InternBDB: FS 2 / FS 2 | InternKon: 674 955 40 / 5
|
|
|
|
08 |
316 212 99
|
Washer |
12 |
InternBDB: 21 /6916 | InternKon: 647 801 40 / 62
|
|
|
|
09 |
500 333 98
|
Bolt (50 mm lg.) |
4 |
InternBDB: M20x50 /933 10.9 | InternKon: 647 801 40 / 60
|
|
|
|
10 |
504 859 98
|
Bolt (120 mm lg.) |
8 |
InternBDB: M20x120 /933 10.9 | InternKon: 647 801 40 / 61
|
|
|
|
11 |
319 305 99
|
Bolt |
24 |
InternBDB: M20x60 /912 10.9 | InternKon: 647 802 40 / 34
|
|
|
|
12 |
385 243 40
|
Flange seal |
6 |
InternBDB: 2 NBR 90 | InternKon: 647 802 40 / 33
|
|
|
|
15 |
500 399 98
|
Weldonplate |
10 |
InternBDB: S-AP-A5
|
|
|
|
16 |
509 064 98
|
Half clamp |
20 |
InternBDB: S-5-E | InternKon: 647 802 40 / 46
|
|
|
|
17 |
500 398 98
|
Plate |
10 |
InternBDB: S-DP-A-5 | InternKon: 647 802 40 / 47
|
|
|
|
18 |
343 008 99
|
Washer |
40 |
InternBDB: 17 /93 | InternKon: 647 802 40 / 50
|
|
|
|
19 |
308 641 99
|
Bolt |
40 |
InternBDB: M16x130 /931 8.8 | InternKon: 647 802 40 / 49
|
|
|
|
20 |
505 212 98
|
Insert |
10 |
InternBDB: S-5-68 | InternKon: 647 802 40 / 48
|
|
