01 |
324 590 40
|
Pressure relief valve, assy. without pressure adjustment |
1 |
InternBDB: Rexroth MO 7004 307 942
|
|
|
|
|$$2 |
|
Fial resetting after mounting required |
-1 |
|
|
|
|
|$$3 |
754 592
|
Bleed-off valve assy. preset 150 bar |
-2 |
|
|
|
|
|$$4 |
754 377
|
Bleed-off valve assy. preset 290 bar |
-2 |
|
|
|
|
|$$5 |
754 378
|
Bleed-off valve assy. preset 300 bar |
-2 |
|
|
|
|
|$$6 |
754 379
|
Bleed-off valve assy. preset 310 bar |
-2 |
|
|
|
|
|$$7 |
754 542
|
Bleed-off valve assy. preset 320 bar |
-2 |
|
|
|
|
|$$8 |
754 538
|
Bleed-off valve assy. preset 340 bar |
-2 |
|
|
|
|
|$$9 |
754 380
|
Bleed-off valve assy. preset 350 bar |
-2 |
|
|
|
|
02 |
994 333
|
Support ring |
1 |
InternBDB: 002 458 24,5x28x0,6
|
|
|
|
03 |
500 302 98
|
O-ring |
1 |
InternBDB: 23,47x2,62 008 972
|
|
|
|
04 |
|
Piston |
1 |
InternBDB: 152 167 Ш 20x35
|
|
|
|
05 |
|
Bush |
1 |
InternBDB: 152 166
|
|
|
|
06 |
|
Compression spring |
1 |
InternBDB: 001 728 11/2x35/8
|
|
|
|
07 |
|
Valve seat |
1 |
InternBDB: 152 168
|
|
|
|
08 |
|
Cone |
1 |
InternBDB: 144 258
|
|
|
|
09 |
994 335
|
Set screw |
1 |
InternBDB: 146 950
|
|
|
|
10 |
994 158
|
Cap |
1 |
InternBDB: 131 745
|
|
|
|
11 |
994 336
|
Nut |
1 |
InternBDB: 144 260
|
|
|
|
12 |
994 265
|
Disk |
1 |
InternBDB: 001 276 6,2x12x0,5
|
|
|
|
13 |
101 484 65
|
O-ring |
1 |
InternBDB: 15x2 004 264
|
|
|
|
14 |
500 303 98
|
O-ring |
1 |
InternBDB: 34,59x2,62 009 338
|
|
|
|
15 |
994 334
|
Compression spring |
1 |
InternBDB: 002 762 8,6/3x31,5/7
|
|
|
|
|$$24 |
994 304
|
Seal kit |
1 |
InternBDB: 309 657
|
|
