01 |
655 523 40
|
Tripple control block assy. |
1 |
InternBDB: Rexroth MO 3447-01/3 MO-52 / 926 649
|
|
|
|
02 |
|
Pressure relief valve |
1 |
InternBDB: 461 498 40 | InternKon: 926 649 / 47
|
090-0404 |
|
|
03 |
763 935 73
|
Housing |
1 |
InternBDB: 821 221 | InternKon: 926 649 / 11
|
|
|
|
05 |
767 751 73
|
Cover |
3 |
InternBDB: 862 931 | InternKon: 926 649 / 21
|
|
|
|
06 |
319 275 99
|
Bolt |
24 |
InternBDB: M12x50 /10.9 - 912 | InternKon: 926 649 / 23
|
|
|
|
07 |
006 852 98
|
O-ring |
6 |
InternBDB: 014 447 110,72x3,53 | InternKon: 926 649 / 24
|
|
|
|
08 |
763 182 73
|
Spring package |
3 |
InternBDB: 545 420 MO-52V10/H2 D75 HUB 26 5,3-20,4 BAR | InternKon: 926 649 / 18
|
|
|
|
10 |
767 749 73
|
Piston (please state fabrication
no. of the block) |
2 |
InternBDB: 826 500 | InternKon: 926 649 / 13
|
|
|
|
11 |
769 098 73
|
Piston (please state fabrication
no. of the block) |
1 |
InternBDB: 862 926 | InternKon: 926 649 / 14
|
|
|
|
12 |
313 504 99
|
Eyebolt |
2 |
InternBDB: M 20 /580 003441 | InternKon: 926 649 / 53
|
|
|
|
13 |
754 576
|
Sealing plate |
6 |
InternBDB: 300 549 | InternKon: 926 649 / 50
|
|
|
|
14 |
756 344 73
|
Seal |
12 |
InternBDB: 003 340
|
|
|
|
15 |
319 275 99
|
Bolt |
24 |
InternBDB: M12x50 /10.9 - 912 | InternKon: 926 649 / 51
|
|
|
|
16 |
763 186 73
|
Taper |
3 |
InternBDB: 814 934 | InternKon: 926 649 / 27
|
|
|
|
17 |
763 187 73
|
Compression spring |
3 |
InternBDB: 002 079 | InternKon: 926 649 / 28
|
|
|
|
18 |
763 188 73
|
Support ring |
3 |
InternBDB: 002 148 | InternKon: 926 649 / 33
|
|
|
|
19 |
502 900 98
|
O-ring |
3 |
InternBDB: 008 940 63,09x3,53 | InternKon: 926 649 / 32
|
|
|
|
20 |
763 189 73
|
Cover |
2 |
InternBDB: 821 229 | InternKon: 926 649 / 29
|
|
|
|
21 |
763 190 73
|
Cover |
1 |
InternBDB: 821 230 | InternKon: 926 649 / 30
|
|
|
|
22 |
763 197 73
|
Cover |
2 |
InternBDB: 821 220 | InternKon: 926 649 / 42
|
|
|
|
23 |
509 822 98
|
Bolt |
8 |
InternBDB: M12x40 /10.9 - 912 | InternKon: 926 649 / 43
|
|
|
|
24 |
763 192 73
|
Cover |
3 |
InternBDB: 821 228 | InternKon: 926 649 / 22
|
|
|
|
25 |
502 745 98
|
O-ring |
2 |
InternBDB: 009 243 66,27x3,53 | InternKon: 926 649 / 44
|
|
|
|
26 |
319 384 99
|
Bolt |
12 |
InternBDB: M20x70 /912 | InternKon: 926 649 / 31
|
|
|
|
27 |
973 126
|
Plug |
2 |
InternBDB: M33x2 | InternKon: 926 649 / 57
|
|
