01 |
624 085 40
|
Intake |
6 |
InternKon: 901 053 40 / 1
|
|
|
|
02 |
226 521 40
|
Seal |
18 |
InternKon: 901 053 40 / 7
|
|
|
|
03 |
307 823 99
|
Bolt |
24 |
InternBDB: M16x35 /933 | InternKon: 901 053 40 / 11
|
|
|
|
04 |
505 966 98
|
Clamp |
12 |
InternBDB: 2 S 156x25 | InternKon: 901 053 40 / 8
|
|
|
|
05 |
901 051 40
|
Suction hose |
2 |
InternBDB: TL | InternKon: 901 053 40 / 3
|
|
|
|
06 |
637 866 40
|
Suction hose |
4 |
InternBDB: TL | InternKon: 901 053 40 / 2
|
|
|
|
07 |
372 431 99
|
Union |
2 |
InternBDB: CL 42 / 2353 | InternKon: 901 053 40 / 12
|
|
|
|
08 |
007 697 98
|
O-ring |
4 |
InternBDB: 69,40 x 3,53 NB 90 | InternKon: 901 053 40 / 18
|
|
|
|
10 |
510 388 98
|
Clamp |
4 |
InternBDB: 2 S 56x20 | InternKon: 901 053 40 / 9
|
|
|
|
11 |
514 176 98
|
Hose DN 60 x 1900 |
4 |
InternBDB: FL 2 1/2 - 45 | InternKon: 901 053 40 / 4
|
|
|
|
12 |
007 630 98
|
Half flange |
8 |
InternBDB: 63 / 210 | InternKon: 901 053 40 / 15
|
|
|
|
13 |
513 499 98
|
Hose DN 40 x 1300 |
2 |
InternBDB: FL 1 1/2 | InternKon: 901 053 40 / 13
|
|
|
|
14 |
513 906 98
|
Hose DN 40 x 850 |
2 |
InternBDB: FL 1 1/2 | InternKon: 901 053 40 / 6
|
|
|
|
15 |
356 209 40
|
Flange seal |
6 |
InternBDB: 1 1/2 | InternKon: 901 053 40 / 17
|
|
|
|
16 |
514 177 98
|
Hose assy.DN 40 x 950 |
2 |
InternBDB: DOL 42 / FL 1 1/2 - 45 | InternKon: 901 053 40 / 5
|
|
|
|
17 |
509 280 98
|
Clamp |
4 |
InternBDB: 2 S 74x25 | InternKon: 901 053 40 / 10
|
|
|
|
18 |
145 825 40
|
Half flange |
4 |
InternBDB: 40 / 210 | InternKon: 901 053 40 / 14
|
|
|
|
19 |
319 156 99
|
Bolt |
40 |
InternBDB: M12 x 30 / 912 | InternKon: 901 053 40 / 16
|
|
|
|
32 |
901 059 40
|
Intake |
6 |
InternBDB: H 455S | InternKon: 901 053 40 / 21
|
|
|
|
33 |
896 710 40
|
Strainer DN 120 |
6 |
InternBDB: Hydac | InternKon: 901 053 40 / 19
|
|
|
|
34 |
307 824 99
|
Bolt |
24 |
InternBDB: M16x40 /931 10.9 | InternKon: 901 053 40 / 22
|
|
