01 |
|
Simplex H.P. Filter |
2 |
InternBDB: 654 807 40 | InternKon: 637 574 40 / 6
|
991-0050 |
|
|
02 |
|
Double H.P. Filter |
2 |
InternBDB: 654 806 40 | InternKon: 637 574 40 / 5
|
991-0049 |
|
|
03 |
510 732 98
|
Resilient sleeve |
13 |
InternBDB: 21 /40x60 | InternKon: 637 574 40 / 12
|
|
|
|
04 |
302 573 99
|
Bolt |
13 |
InternBDB: M20x100 /931 10.9 | InternKon: 637 574 40 / 14
|
|
|
|
05 |
510 733 98
|
Resilient sleeve |
4 |
InternBDB: 17 /30x50 | InternKon: 637 574 40 / 13
|
|
|
|
06 |
308 321 99
|
Bolt |
4 |
InternBDB: M16x90 /931 10.9 | InternKon: 637 574 40 / 15
|
|
|
|
07 |
643 709 40
|
Hose assy. DN 50 x 2670 |
1 |
InternBDB: FS 2 / FS 2 90 | InternKon: 637 574 40 / 41
|
|
|
|
08 |
358 691 40
|
Hose assy. DN 50 x 2360 |
2 |
InternBDB: FS 2 / FS 2 90 | InternKon: 637 574 40 / 42
|
|
|
|
09 |
319 305 99
|
Bolt |
24 |
InternBDB: M20x60 /912 10.9
|
|
|
|
10 |
385 243 40
|
Tetra seal |
6 |
|
|
|
|
11 |
515 812 98
|
Coupling |
-2 |
InternKon: 637 574 40 / 22
|
|
|
|
21 |
653 697 40
|
Hose assy. DN 40 x 1285 |
1 |
InternBDB: FS 2 - 90 / FS 1 1/2 | InternKon: 637 573 40 / 31
|
|
|
|
22 |
653 696 40
|
Hose assy. DN 40 x 1370 |
1 |
InternBDB: FS 2 - 90 / FS 1 1/2 | InternKon: 637 573 40 / 32
|
|
|
|
23 |
356 209 40
|
Flange seal |
4 |
InternBDB: 1 1/2 NBR 90 | InternKon: 637 573 40 / 13
|
|
|
|
24 |
319 288 99
|
Bolt |
16 |
InternBDB: M16x50 /912 10.9 | InternKon: 637 573 40 / 19
|
|
|
|
25 |
385 243 40
|
Flange seal |
-2 |
InternBDB: 2 NBR 90 | InternKon: 637 573 40 / 12
|
|
|
|
26 |
506 582 98
|
Plug |
1 |
InternBDB: A2-6000 | InternKon: 637 573 40 / 20
|
|
|
|
27 |
319 310 99
|
Bolt |
4 |
InternBDB: M20x50 /912 10.9 | InternKon: 637 573 40 / 21
|
|
|
|
30 |
509 064 98
|
Half clamp |
20 |
InternBDB: S-5-E
|
|
|
|
31 |
500 399 98
|
Weld on Plate |
10 |
InternBDB: S-AP-A-5
|
|
|
|
32 |
505 212 98
|
Insert |
10 |
InternBDB: S-5-68
|
|
|
|
33 |
500 398 98
|
Plate |
10 |
InternBDB: S-DP-A-5
|
|
|
|
34 |
343 008 99
|
Washer |
20 |
InternBDB: 17 /93
|
|
|
|
35 |
308 641 99
|
Bolt |
20 |
InternBDB: M16x130 /931 8.8
|
|
|
|
40 |
896 530 40
|
Pressure measuring transducer
500 bar |
2 |
InternBDB: Hydac HDA 4740-B-600-142 | InternKon: 637 573 40 / 50
|
|
|
|
41 |
371 883 99
|
Socket |
2 |
InternBDB: EVGE 8 PSR-ED | InternKon: 637 573 40 / 51
|
|
|
|
42 |
372 180 99
|
Union |
2 |
InternBDB: DDS 8 | InternKon: 637 573 40 / 52
|
|
|
|
43 |
371 972 99
|
Union |
2 |
InternBDB: FFS 8 | InternKon: 637 573 40 / 53
|
|
|
|
44 |
514 190 98
|
Coupling |
2 |
InternBDB: 8 S | InternKon: 637 573 40 / 54
|
|
|
|
45 |
515 810 99
|
Union |
2 |
InternBDB: GAI 8-PSR | InternKon: 637 573 40 / 55
|
|
