H455-SD S/N 15009

Komatsu parts book diagram for H455-SD S/N 15009: BLEED-OFF VALVE, PRE-CONTROLLED

01 02 03 03 04 04 05

	#	Part Number	Partname	Quantity	Options	Reference
	01	906 861 40	Bleed-off valve, pre-controlled assy. without pressure adjustment	-2	InternBDB: Rexroth MO-7090 364 759 MH1DBV32-P"-1X/420YM
	\|$$2		Fial resetting after mounting required	-2
	\|$$3	356 197 40	Valve, pre-controlled assy. 150bar	-2
	\|$$4	356 198 40	Valve, pre-controlled assy. 350bar	-2
	\|$$5	324 559 40	Valve, pre-controlled assy. 125bar	-2
	\|$$6	414 238 40	Valve, pre-controlled assy. 180bar	-2
	\|$$7	414 239 40	Valve, pre-controlled assy. 190bar	-2
	\|$$8	655 571 40	Valve, pre-controlled assy. 310bar	-2
	\|$$9	906 711 40	Valve, pre-controlled assy. 280bar	-2
	\|$$10	414 967 40	Valve, pre-controlled assy. 330bar	-2
	\|$$11	621 732 40	Valve, pre-controlled assy. 320bar	-2
	02		Pressure relief valve	1	InternBDB: M 7004 307 942	090-0186
	03	368 097 40	Support ring	2	InternBDB: 194 313
	04	000 157 98	O-ring	2	InternBDB: 18x2,5 80 Sh
	05	994 304	Seal kit to fig-no: 02	1	InternBDB: 309 657

Komatsu H455-SD S/N 15009 parts catalog PDF

BLEED-OFF VALVE, PRE-CONTROLLED (090-0359) in H455-SD S/N 15009. Diagram image and parts list.
